Linear Light 38x36x1000mm
Linear Light 38x36x1000mm
Linear Light 38x36x1000mm
Linear Light 38x36x1000mm
Linear Light 38x36x1000mm

Linear Light 38x36x1000mm

Model NO.:
SL413.3836
Delivery:
FOB
Quantity:

 Features

  • Optics: Private mode customized lens, with accurate light distribution;

  • Waterproof: Original triple structure with glue waterproof patent,private mold water-proof connector and reliable waterproof performance, up to IP68;

  • Installation: Modular fast installation, cost saving;

  • Material: Aluminum alloy housing, customizable housing color, high strength tempered transparent glass;

  • Application: Outdoor architectural lighting.


 Size


 Specification

  • LED Type: Cree, Osram, Lumileds, Nichia etc.

  • Input Voltage: 24VDC/48VDC

  • Power Rating: 36W

  • Beam Angle: 12°

  • Color Temperature: Single color, RGB, RGBW

  • Life Span: ≥50000 hrs

  • Housing: Aluminum alloy body, tempered glass cover

  • Dimension: 38x36x1000mm

  • Weight: 1.7kg

  • Working Temperature: -30°C ~+65°C

  • Control:  ON/OFF,DMX512

  • Ingress Protection: IP66

  • Classification: III


 Fixture Options

SpecLengthPowerLens Optional accessories
38x36350mm12W12°,15°,20°,30°,45°,12*36°,25*45°,10*60°,
30*65°
boardwire groovecontinuous connection in seriescut-off frosted glassanti-glare grilleanti-drop rope
500mm18W
1000mm36W
1200mm42W
