Linear Light 42x65x1000mm
Linear Light 42x65x1000mm
Linear Light 42x65x1000mm
Linear Light 42x65x1000mm
Linear Light 42x65x1000mm

Linear Light 42x65x1000mm

Model NO.:
SL413.4265
Delivery:
FOB
Quantity:

 Features

  • Optics: Optical private mode customized lens, with accurate light distribution;

  • Waterproof: Original triple structure with glue waterproof patent,private mold water-proof connector and reliable waterproof performance, up to IP68;

  • Installation: Modular fast installation, cost saving;

  • Material: Aluminum alloy housing, customizable housing color, high strength

  • tempered transparent glass, built-in anti-glare grille;

  • Application: Outdoor architectural lighting.


 Size


 Specification

  • LED Type: Cree, Osram, Lumileds, Nichia etc.

  • Input Voltage: 24VDC/48VDC

  • Power Rating:  48W

  • Beam Angle: 12°

  • Color Temperature: Single color, RGB,RGBW

  • Life Span:  ≥50000 hrs

  • Housing: Aluminum alloy body, tempered glass cover

  • Dimension: 42x65x1000mm

  • Weight:  2.2kg

  • Working Temperature: -30°C ~+65°C

  • Control:  ON/OFF, DMX512

  • Ingress Protection: IP67

  • Classification: III


 Fixture Options

SpecLengthPowerLens Optional accessories
42x65350mm18W12°,15°,20°,30°,45°,60°,12*36°,25*45°,10*60°,
30*65°
boardwire groovecontinuous connection in seriescut-off frosted glassanti-glare grilleanti-drop rope
500mm24W
1000mm48W
