Linear Light 15x25x1000mm
Linear Light 15x25x1000mm
Linear Light 15x25x1000mm
Linear Light 15x25x1000mm
Linear Light 15x25x1000mm
Linear Light 15x25x1000mm
Linear Light 15x25x1000mm
Linear Light 15x25x1000mm
Linear Light 15x25x1000mm

Linear Light 15x25x1000mm

Model NO.
SL413.1525
Delivery:
EXW
Quantity:

  Features

  • Optics: Light output 120 °;

  • Waterproof: Patented waterproof design, private mold water-proof connector and reliable waterproof performance, up to IP68;

  • Installation: Modular fast installation, cost saving;

  • Material: Aluminum alloy housing, customizable housing color,anti-UV PC cover;

  • Application: Outdoor architectural lighting.


  Size


 Specification

  • LED Type: Cree, Osram, Lumileds, Nichia etc.

  • Input Voltage: 24VDC

  • Power Rating: 10W

  • Beam Angle: 120°

  • Color Temperature: Single color, RGB, RGBW, RGB+W

  • Life Span: ≧50000 hrs

  • Housing: Aluminum alloy body, PC cover

  • Dimension: 15x25x1000mm

  • Weight:  0.6kg

  • Working Temperature: -30°C ~+65°C

  • Control:  ON/OFF, DMX512

  • Ingress Protection: IP66

  • Classification: III


 Fixture Options

SpecLengthPowerLens Optional accessories
15x25350mm2.5W120°boardwire groovecontinuous connection in seriesanti-drop rope
500mm5W
1000mm10W
1200mm12.5W
