Linear Light 17x31x1000mm
Linear Light 17x31x1000mm
Linear Light 17x31x1000mm
Linear Light 17x31x1000mm
Linear Light 17x31x1000mm

Linear Light 17x31x1000mm

Model NO.
SL413.1731
Delivery:
EXW
Quantity:

 Features

  • Optics : Light even and uniform;

  • Waterproof : Patented waterproof design, private mold water-proof connector and reliable waterproof performance, up to IP68;

  • Installation : Modular fast installation,cost saving;

  • Material : Aluminum alloy housing, customizable housing color,anti-UV PC cover;

  • Application : Outdoor architectural lighting.


 Size


 Specification

  • LED Type: Cree, Osram, Lumileds, Nichia etc.

  • Input Voltage: 24VDC/48VDC

  • Power Rating: 12W

  • Beam Angle: 120°

  • Color Temperature: Single color,RGB,RGBW,amber

  • Life Span: ≧50000 hrs

  • Housing: Aluminum alloy body, milky PC cover

  • Dimension: 17x31x1000mm

  • Weight:  0.8kg

  • Working Temperature: -30°C ~+65°C

  • Control: ON/OFF, DMX512

  • Ingress Protection: IP66

  • Classification: III


 Fixture Options

SpecLengthPowerLens Optional accessories
17x31350mm4W120°boardwire groovecontinuous connection in seriesanti-drop rope
500mm6W
1000mm12W
1200mm14W
