Linear Light 20x23x1000mm
Linear Light 20x23x1000mm
Linear Light 20x23x1000mm
Linear Light 20x23x1000mm
Linear Light 20x23x1000mm

Linear Light 20x23x1000mm

Model NO.
SL413.2023
Delivery:
EXW
Quantity:

  Features

  • Optics: Light output 120 °;

  • Waterproof: Patented waterproof design, private mold water-proof connector and reliable waterproof performance, up to IP68;

  • Installation: Modular fast installation, cost saving;

  • Material: Aluminum alloy housing, customizable housing color, anti-UV PC cover;

  • Application: Outdoor architectural lighting.


 Size


 Specification

  • LED Type: Cree, Osram, Lumileds, Nichia etc.

  • Input Voltage: 24VDC/48VDC

  • Power Rating:    12W

  • Beam Angle: 120°

  • Color Temperature: Single color,amber

  • Life Span: ≧50000 hrs

  • Housing: Aluminum alloy body, translucent PC cover

  • Dimension: 20x23x1000mm

  • Weight: 0.5kg

  • Working Temperature: -30°C ~+65°C

  • Control: ON/OFF

  • Ingress Protection: IP66

  • Classification: III


 Fixture Options

SpecLengthPowerLens Optional accessories
22x23350mm3.7W120°boardwire groovecontinuous connection in seriesanti-drop rope
500mm7.5W
1000mm15W
1200mm18.7W
