Linear Light 24x35x1000mm
Linear Light 24x35x1000mm
Linear Light 24x35x1000mm
Linear Light 24x35x1000mm
Linear Light 24x35x1000mm

Linear Light 24x35x1000mm

Model NO.
SL413.2435
Delivery:
EXW
Quantity:

  Features

  • Optics: Private mode customized lens, with accurate light distribution;

  • Waterproof: Original triple structure with glue waterproof patent,private mold water-proof connector and reliable waterproof performance, up to IP68;

  • Installation: Modular fast installation, cost saving;

  • Material: Aluminum alloy housing, customizable housing color,

  • anti-UV PC cover;

  • Application: Outdoor architectural lighting.


 Size


 Specification

  • LED Type: Cree, Osram, Lumileds, Nichia etc.

  • Input Voltage: 24VDC/48VDC

  • Power Rating:  12W

  • Beam Angle:120°(no lens)

  • Color Temperature: Single color,RGB,RGB+W

  • Life Span:  ≧50000 hrs

  • Housing: Aluminum alloy body, milky white PC cover

  • Dimension: 24x35x1000mm

  • Weight: 0.79kg

  • Working Temperature: -30°C ~+65°C

  • Control:  ON/OFF,DMX512

  • Ingress Protection: IP66

  • Classification: III


 Fixture Options

SpecLengthPowerLens Optional accessories
24x351000mm12W

120°

boardwire groovecontinuous connection in seriesanti-drop rope
