Linear Light 25x25x1000mm
Linear Light 25x25x1000mm
Linear Light 25x25x1000mm
Linear Light 25x25x1000mm
Linear Light 25x25x1000mm

Linear Light 25x25x1000mm

Model NO.
SL413.2525
Delivery:
EXW
Quantity:

 Features

  • Optics: Light output 120 °;

  • Waterproof: Original triple structure with glue waterproof patent,private mold water-proof connector and reliable waterproof performance, up to IP68;

  • Installation: Modular fast installation, cost saving;

  • Material: Aluminum alloy housing, customizable housing color,anti-UV PC cover;

  • Application: Outdoor architectural lighting.


 Size


 Specification

  • LED Type: Cree, Osram, Lumileds, Nichia etc.

  • Input Voltage: 24VDC / 48VDC

  • Power Rating: 15W

  • Beam Angle: 120°

  • Color Temperature: Single color, RGB,RGBW,amber

  • Life Span:  ≥50000 hrs

  • Housing: Aluminum alloy body, translucent PC cover

  • Dimension: 25x25x1000mm

  • Weight:  0.8kg

  • Working Temperature: -30°C ~+65°C

  • Control:  ON/OFF, DMX512

  • Ingress Protection: IP66

  • Classification: III


 Fixture Options

SpecLengthPowerLens Optional accessories
25x25350mm3.7W

120°

boardwire groovecontinuous connection in seriesanti-drop rope
500mm7.5W
1000mm15W
1200mm18W
