EN / CN
LED Brick φ200x62mm
LED Brick φ200x62mm
LED Brick φ200x62mm

LED Brick φ200x62mm

Model NO.
SL308.20062
Delivery:
EXW
Quantity:

 Features

  • IP67,anti-scratch, anti-wear, acid & alkali resistant;

  • Surface texture Mohs'scale of hardness up to 5°;

  • Customizable texture,pattern,size & shape;

  • Interactive induction available, game interaction program implantable, with strong experience feeling;

  • Suit for municipal and commercial squares, garden paths, cultural tourism projects, etc.


 Size


 Specification

  • LED Type: Cree, Osram, Lumileds, Nichia etc.

  • Input Voltage: 24VDC

  • Power Rating:  2.6W

  • Beam Angle: 120°

  • Color Temperature: White,R,G,B,RGB,RGBW,amber

  • Life Span: ≧50000 hrs

  • Housing: Stainless steel body, high-strength tempered glass cover

  • Dimension: φ200x62mm

  • Weight: 5kg

  • Working Temperature: -30°C ~+65°C

  • Control: ON/OFF,DMX512

  • Ingress Protection: IP67

  • Classification: III

  • Installation: Embedded buried installation (recessed box required)


 Fixture Options

SizePowerLED colorTextureVoltageControlOther options
φ67x62mm1.3WSingle color,RGB,RGB+W,RGBWGranite,Caesar Grey, Yellow Granite,Red Granite, etc24VDCON/OFF, DMX512Drive over ≤5TContinuous connection in series
φ100x62mm1.3W
φ150x62mm2W
φ200x62mm2.6W
φ300x62mm6W
